cemented carbide down hole drill bit button inserts

cemented carbide down hole drill bit button inserts

Place of Origin： China
Brand Name： ZhuZhou Top
Certification： ISO9001:2015
Grade： ZF00129
Minimum Order Quantity:100 pcs
Price:USD 0.1-2/pcs
Delivery Time:7-15 days
Payment Terms:30% after confirming order the balance before shiping
Supply Ability:100000 pcs/month

cemented carbide down hole drill bit button inserts

If have any more information, please feel free to contact with me. And warmly welcoem to visit our factory.

Conter person:Sharon Chen

Email:sharon@xtjqxcl.com

Mobile/Whatsapp phone:+86-181733888506

Website:www.wmcarbide-rods.com

Tungsten carbide buttons:

1.Products description

Tungsten carbide buttons are mainly used for high and low pressure DHT drill and hydraulic Screw-in drill and so on.

They are suitable for hot insert or cold pressing bit inserting process, With some of the materials used in the welding process. These products are stable in quality,Excellent in performance, can meet or exceed the domestic advanced level.

We are developing carbide grades use in crushing and recycling industry. Tire, plastic, metals and trashes that needs to break down and recycle. Weariness, toughness and resistance to acidy working environment are essential properties. Specific develop grades working with different crushing materials improves the runtime of your equipment.

2.Mining button bits

Normal grade suggestions

Grade	Density (g/cm3)	Hardness (HRA)	TRS (MPa)	Applications recommended
YG8	14.80	89.5	2200	For coring crowns, electric coal drill bits, coal cutting picks, oil cone bits and scraping knife bits, used in geological prospecting, coal mining and oil well boring.
YG8C	14.80	88.5	2400	Mostly used as the buttons of small and medium sized percussion bits and as the inserts of rotary prospecting bits to cut soft and medium hard formations.
YG11C	14.40	87.00	2850	Suitable for embedding rotary percussive drill bits of heavy rock drilling machines for drilling hard formations of class f=18 or above
YK05	14.95	90.5	2500	Mostly used as the buttons of small and medium sized percussion bits and as the inserts of rotary prospecting bits to cut soft and medium hard formations.
YK15	14.60	87.6	2700	Suitable for embedding rotary percussive drill bits of light rock drilling machines for drilling medium rock formations of class f=14-15
YK20	14.52	87.3	2650	Suitable for embedding rotary percussive drill bits of medium rock drilling machine for drilling hard rock formations of class f=18 or above.
YK25	14.40	87.2	2550	Primarily for the buttons and inserts of rotary percussion bits to cut medium-hard and very hard formations

Application:

Tungsten Carbide ball tooth is widely used in oil drilling and snow removal of snow plough device.In addition, carbide ball tooth in the cutting tool and coal mining machinery, road maintenance and drill tool also has a good application.Mining with cemented carbide balls tooth mainly used for quarrying, mining, and mining tools in tunnel and civil construction.

Virgin Material Cemented Tungsten Carbide Wear Parts Button Teeth For Drilling Bits(图1)

Carbide button type

1. Spherical carbide button type
2. Conical Carbide button Type
3. Ballistic Carbide Button type
4. Scoop Carbide Button Type
5. Wedged Carbide button Type
6. Flat Carbide button Type
