Custom Tungsten Carbide Parts

  • High Wear Resistance Custom Solid Tungsten Carbide Guiding Sleeve
  • High Wear Resistance Custom Solid Tungsten Carbide Guiding Sleeve
  • High Wear Resistance Custom Solid Tungsten Carbide Guiding Sleeve
High Wear Resistance Custom Solid Tungsten Carbide Guiding Sleeve High Wear Resistance Custom Solid Tungsten Carbide Guiding Sleeve High Wear Resistance Custom Solid Tungsten Carbide Guiding Sleeve

High Wear Resistance Custom Solid Tungsten Carbide Guiding Sleeve

  • Place of Origin： Zhuzhou, Hunan
  • Brand Name： ZhuZhou Top
  • Certification： ISO9001:2015
  • Grade： YN9 YN8 YG8 Yg6
  • Minimum Order Quantity:10 pcs
  • Price:Negotiable
  • Delivery Time:3-15days
  • Payment Terms:L/C, D/A, D/P, T/T, Western Union
  • Supply Ability:15tons/month

High Wear Resistance Custom Solid Tungsten Carbide Guiding Sleeve

Tungsten carbide bushing set up by virgin tungsten carbide material. It’s shows high hardness and bending strength. That has superior performance on resisting abrasion and corrosion, which is widely used in many industries.

For its widely usage. Tungsten carbide bushing are often made with high accuracy, and owing to their perfect finish, precise dimension, durability and corrosion resistance. These are highly appreciated by the clients at home and aboard.

In addition, differ from the various of application environment. There are several types of Tungsten carbide bushing. Most of the specifications are all customized.

Grade of tungsten carbide bushing


Grade
Density(g/cm3)
T.R.S. (MPa)
Performance & application recommended
YG6A
14.95
1800
Fine grain alloy, good wear resistance. Semi-finishing of chilled cast iron,
non-ferrous metals alloys, semi-finishing and finishing of hardened steel, alloy steel.
YG8
14.8
2200
High strength in use, impact and shock resistance higher than YG6, but wear resistance and cutting speed comparatively lower
YN8
14.8
2000
Corrosion Resistant, It widely used in chemical and petroleum pumps
YL10.2
14.5
2800
Fine grain alloy, good wear resistance. Used for processing hard wood, veneer board,  PCB, PVC and metals
Application of tungsten carbide Sleeves
Tungsten carbide bushing applications is wide, which is a device to protect a class of components. It is in the actual work and the role and purpose of its application environment have a great relationship.


Valve applications:
bushings be installed in the valve stem cap trap, in order to reduce the valve leakage, to seal;
bearing applications,
the use of bush to reduce wear between the bearing and the shaft seat, avoid the gap between the shaft and the hole increases and so on.

Tungsten carbide bushing production and processing of high-strength, can withstand prolonged load, with high chemical stability, alkali, alcohol, ether, hydrocarbons, acid, oil, detergent, water (sea water), and has no smell , non-toxic, tasteless, non-rust characteristics, its widely used in petrochemical industry for Submerged Oil Pump, slurry pump, water pump, Centrifugal Pump,etc.

Flow Guiding Application

As wear parts,guiding flow in the expansion joint, protecting the bellows

Product feature of tungsten carbide Sleeves
1. High hard resistance
2. High corrosion resistance
3. Pressured resistance
4. Wear resistance

5. High bending strength


For more infomation, please contact me

Ms shirley Pan

Email: sales@topcarbide.com

Mobile/Whatsapp: +86 17773379950
