Ground Tungsten Carbide Rod

Customized ground tungsten carbide round rod for end mill

Customized ground tungsten carbide round rod for end mill

Place of Origin： China
Brand Name： ZhuZhou Top
Certification： ISO9001:2015
Grade： ZF0047
Minimum Order Quantity:10 pcs
Price:USD 45-58/kg
Delivery Time:3-5 days
Payment Terms:100% TT before shiping
Supply Ability:100000 pcs/month

Customized ground tungsten carbide round rod for end mill

Specifications

A. Overpressure sintering tungsten carbide rod have excellent red toughness,high hardness,good wear resistance,high elasticmodulus,high strength,good chemical stability,acid,alkali,high temperatureoxidation),Low impact toughness,low

expansion coefficient,thermal conductivity,the characteristics of the conductive similar to iron and other alloy.

1. having all kind sizes for your choose,can suply less than 1000mm length.

2. Sintere by vacuum sintering furnace and HIP machine with excellent specifications without any hole.

3. suply blank plate with tolerance(-0.15~+0.15)or (0~+0.3).

4. can grinding and polishing the diameter, making chamfer,sharper rod end.

5. process the carbide rod according your request and tolerances.

Grades choosing

Grade	Density(g/cm3)	Hardness (HRA)	T.R.S (MPa)	Grain size (μm)	Composition (%)	Equal to ISO
YU12	14.1~14.15	.≥92.5	≥4000	0.2~0.5	12% CO 88% WC	K40~K50
YL10.2	14.4~14.6	≥92.2	≥4000	0.6~0.8	10% CO 90% WC	K20~K30
YG6X	14.85~15.0	≥92.0	≥3860	0.8~1.0	6% CO 94% WC	K05
YG15	14.0~14.1	≥85.0	≥2800	1.2~2.0	15%Co 85% WC	K30~K40
YG10	14.5~14.6	≥85.5	≥2600	1.2~2.0	10%Co 90% WC	K20
YG8	14.65~14.85	≥89.5	≥2320	1.2~2.0	8% CO 92% WC	K20
YG6	14.85~15.05	≥90.0	≥2150	1.2~2.0	6% CO 94% WC	K10

Sizes choosing

Diameter(mm)	Length(mm)	grinding and polishing
0.3~1.0	5~330	h6,h7,H6 or H7
1.0~3.0	5~330	h6,h7,H6 or H7
4.0~80	5~1000	h6,h7,H6 or H7

Applications
having high red hardness, good weldability and the characteristics of high hardness, high wear resistance,
mainly used in making solid wood processing, density board, grey cast iron,Non-ferrous metal materials,
chilled cast iron, hardened steel, PCB, brake materials.When using, should according to specific purpose
to choose the right material of tungsten carbide bar.
