Tungsten Carbide Blade
High Performance Cemented Carbide Circular Blade For Cigarette Cutting
- Place of Origin： Zhuzhou, Hunan
- Brand Name： ZhuZhou Top
- Certification： ISO9001:2015
- Grade： ZF-C128
- Minimum Order Quantity:10 pcs
- Price:negotiable
- Delivery Time:3-20days
- Payment Terms:L/C, D/A, D/P, T/T, Western Union
- Supply Ability:15tons/month
For more information, warmly welcomr to contact me
Sharon Chen
Email:sharon@xtjqxcl.com
Mobile/Whatsapp:0086-18973341595
High Performance Cemented Carbide Circular Blade For Cigarette Cutting
Various dimension for reference(We can manufacture based on your drawing)
| Types of discs unit:mm | |||
| TYPE | D | d | S |
| Φ12×Φ6×S | 12 | 6 | 0.6-4.5 |
| Φ13×Φ6×S | 13 | 6 | 0.6-4.5 |
| Φ16×Φ6×S | 16 | 6 | 0.6-4.5 |
| Φ22×Φ10×S | 22 | 10 | 0.6-4.5 |
| Φ25×Φ12×S | 25 | 12 | 0.6-5.5 |
| Φ32×Φ10×S | 32 | 10 | 0.8-5.5 |
| Φ40×Φ10×S | 40 | 10 | 0.8-6.0 |
| Φ45×Φ13×S | 45 | 13 | 0.8-6.0 |
| Φ53×Φ13×S | 53 | 13 | 0.8-6.0 |
| Φ52×Φ24.5×S | 52 | 24.5 | 0.8-6.0 |
| Φ53×Φ24.5×S | 53 | 24.5 | 0.8-6.0 |
| Φ55×Φ16×S | 55 | 16 | 0.8-6.0 |
| Φ58×Φ22×S | 58 | 22 | 0.8-6.0 |
| Φ60×Φ19×S | 60 | 19 | 0.8-7.0 |
| Φ63×Φ17×S | 63 | 17 | 0.8-7.0 |
| Φ70×Φ22×S | 70 | 22 | 0.8-7.0 |
| Φ75×Φ22×S | 75 | 22 | 0.8-7.0 |
| Φ80×Φ22×S | 80 | 22 | 0.8-7.0 |
| Φ83×Φ21×S | 83 | 21 | 0.8-7.0 |
| Φ86.5×Φ21.5×S | 86.5 | 21.5 | 1.0-7.0 |
| Φ90×Φ22×S | 90 | 22 | 1.0-7.0 |
| Φ100×Φ22×S | 100 | 22 | 1.0-7.0 |
| Φ140×Φ40×S | 140 | 40 | 0.55-6 |
| Φ200×Φ70×S | 200 | 70 | 3.0-4.5 |
| Φ250×Φ70×S | 250 | 70 | 3.0-4.5 |
| Φ250×Φ95×S | 250 | 95 | 3.0-4.5 |
| Other types be offered by customers' requirement | |||
Some Recommended Grade for Reference
Grade | ISO | Cobalt % | Density(g/cm3) | Hardness(HRA) | Application |
YG8 | K30 | 8 | 14.8 | 89.5 | The first choice for non-ferrous metal cutting |
YG6 | K20 | 6 | 14.95 | 90.5 | |
YG6X | K10 | 6 | 14.95 | 91.5 | suitable for Chilled alloy cast iron, heat-resistant alloy steel , common castiron |
YL10.2 | K25-K35 | 10 | 14.5 | 91.8 | For all kinds of metal working |
YS2T | K30 | 10 | 14.5 | 92 | |
| YG12X | 12 | 14.6 | 89.5 | cutting filter,ciga. etc. |
More dimension and grades please kindly contact us. We have various grade and size to meet you.
Application of tungsten carbide circular blade
For cutting paper, rubber, plastic, soft metal, wood, MDF, etc.
The carbide circular blades for Slitting Corrugated Board, carbide rotary blade for rubbers cutting, carbide blade for battery industry, carbide blades for Tobacco Machines, carbide circuit board cutting knife, carbide blades for metal cutting, carbide knife for Rewinder machines, carbide blades for chemical fiber cutting, carbide blades for printing industry, carbide milling cutter for paper industry, and carbide blades for other special range.
Production Process:
Powder preparing-Pressing-Sintering-Processing- Finishing
OurＡdvantages
1. Our products adopt spray drying tower granulation, raw material with low oxygen content, contamination,the flowability,
apparent density particle and granulate is uniform;
2. Adopting high-precision CIP molding machine, uniform product density, precise dimension,high roundness, and flatness;
3. Adopting advanced HIP sintering, effectively eliminate the internal holes and defects, the product has good compactness,
high strength, good polishing performance;
4. Adopting a special stress-relief process to eliminate the internal stress of products to further enhance the product
strength and improve the microstructure;
5. Long lifetime
Our packing
step 1, wrapped carbide blades in paper to avoid carbide blade be broken
step 2, put the carbide blade in inner small carton box
step 3, put the inner box into outer carton and fill the carton with foamed plastic
step 4, wrap the carton with packaging tape
Warmly welcome to contact us for your needs. We will meet your any requirement with our professional technic and advance equipment
