Tungsten Carbide Nozzle

K20 Wear Resisitance Tungsten Carbide Nozzle HRA92-93 Hardness Customized

Place of Origin： Zhuzhou, Hunan
Brand Name： ZhuZhou Top
Certification： ISO9001:2015
Grade： ZF-N26
Minimum Order Quantity:100pcs
Price:negotiable
Delivery Time:3-15days
Payment Terms:L/C, D/A, D/P, T/T, Western Union
Supply Ability:15tons/month

For more information, warmly welcome to contact me

Sharon Chen

Email:sharon@xtjqxcl.com

Mobile/Whatsapp: 0086-18973341595

K20 Wear Resisitance Tungsten Carbide Nozzle HRA92-93 Hardness Customized

Recommen Grade information

Grade	Density(g/cm3)	Hardness(HRA)	TRS(MPa)	grain Size	Composition
YG6X	14.95	92	1800	0.6um	6%Co+94% WC
YG6	14.95	90	1900	0.8-1.2um	6%Co+94% WC
YL10.2	14.6	92.8	4000	0.6-0.7um	10%Co+90% WC
YG10X	14.5	93	3500	0.4-0.6um	10%Co+90% WC

Unique advantage of tungsten carbide water jet nozzles

1. Adopt supermicron grain size, which can result in better wear-reseistance and longer life span.

2. Super oxygen-resistant

3. Using HIP sintering which can increase the performance of carbide greatly.

4. Precision Ground and polished

Detail information:

1. Size: Φ10**5mm( customized is also available)

2. Material: tungsten carbide(WC+Co)

3. Hardness: HRA92.5-93

4. Application: waterjet cutting head

Physic character of tungsten carbide water jet nozzles

1. Long life span: 80 hrs for finish grinding, 140hrs for rough grinding

2. Density:15.45g/cm3 —15.60 g/cm3

3. Hardness:2000Mpa-2400Mpa

4. the tolerance of polish and ground can be +0.005/-0.005m

high hardness and excellent wear resistance tungsten carbide nozzle

Carbide water jet nozzle made from high hardness tungsten carbide, the life time is 10 times longer than ceramic nozzles. They are good for cleaning, even small areas: weldments, grillwork, and railings. It can be used with water from a tap or with rust inhibitors introduced through any simple pump, no special equipment is required. If your needed a non-standard nozzle, we also can produce it for you.

Application of tungsten carbide nozzles

1.Metal cutting

2.Ceramic cutting

3.Stone cutting

4.Glass cutting

Advantages of Tungsten Carbide Nozzle

Cost effective

Good performance property of abrasive resistance

corrosion resistance

stable property performance and long service life.

Customized nozzles are available according to your drawing and application.
