Tungsten Carbide Rods
Great Precision Ground Tungsten Carbide Needle / Pin With High Hardness
- Place of Origin： China
- Brand Name： ZhuZhou Top
- Certification： ISO9001:2015
- Grade： ZF0034
- Minimum Order Quantity:10 pcs
- Price:USD 55-65/kg
- Delivery Time:7-15 days
- Payment Terms:100% TT before shiping
- Supply Ability:100000 pcs/month
Great Precision Ground Tungsten Carbide Needle / Pin With High Hardness
Description and Application
Tungsten Carbide is often referred to as a Hard Metal due to it’s very high hardness in relation to other metals. Typically a
Tungsten Carbide can have a hardness value of 1600 HV, whereas mild steel would be in the region of 160 HV a factor of 10 lower. Tungsten Carbide Rods are used for cutting aluminum alloy, cast iron, stainless steel, refractory alloy steel, nickel based alloy, titanium alloy and nonferrous metals. With several years’ development, with our good quality and competitive price, our products have been widely recognized by worldwide makers of cutting tools. We are looking forward to establish new business with new customers.
| Dimension | Dia 1mm, 1.5mm, 2mm, 2.5mm, 3mm, 4mm, till 25mm with length 5mm, 8mm, 10mm, till 330mm, cut to length |
| Cutting angles | 30°, 45°, 60°, 90°, 120°. Or Based On Requirement |
| Material | 100% virgin tungsten carbide steel |
| grade | YL10.2 |
| Hardness | HRA92.5-92.8 |
| Composition | 10%Co+90%WC |
| Grain Size | 0.6um |
| Surface | unground |
| Features | durable high wear resistance Replaceable Very Sharp Point Create Fine Edge |
| Application | Assembling On Tool Bit, Engraving or Scribing On Very Hard Items, For Example: Aluminum, Brass, Bronze, Metals, Steel, Glass, Ceramics, Hardwood, Etcs |
Some size
| D(mm) | L(mm) | α |
| 1.5 | 5 | 40°-90° |
| 2 | 10 | 40°-90° |
| 2.5 | 10 | 40°-90° |
| 3 | 18 | 40°-90° |
| 3 | 10 | 40°-90° |
| 3.5 | 10 | 40°-90° |
| 4 | 20 | 40°-90° |
| Other size can be customized |
* ISO 9001:2015 Certification
* Use 100% tungsten carbide raw material
* Advanced technology , automatic pressing , HIP sintering
* with over ten year experience
* And precision grinding
* the tolerance of polish and ground can be +0.005/-0.005mm
* Full ability to accept OEM & ODM orders
* Stringent quality control and quality consistency.
* Strict inspection for quality of raw material and finished products
We Guarantee:
1. produced with advanced equipments and process.
2. high quality durable tungsten carbide rod blanks/cemented rods for milling for router bits made from 100% virgin raw material.
3. all products go through in-process and final inspection.
4. Quality Control System and strict inspection.
5. stable and continuous production ability.
6. free online technical service available.
7. OEM and ODM are accepted as well.
8. Our solid carbide rods are known for constantly providing maximum quality. You can rely on our products as a basis for
consistent performance capacity of your tools.
9. Undertake orders of non-standard sizes at customer's requests.
We can offer a lot of type tungsten carbide rods:
1. un-gound, finish-ground in metric and imperial diameters;2. Carbide rods with central coolant duct;
3. Fixed length Carbide Rod
4. Random Length carbide rod
5. Carbide rods with chamfered end.
1. Tungsten Carbide rod
2. Tungsten Carbide Sealed Ring
3. Tugnsten Carbide Wear parts
4. Tugnsten Carbide Dies
5. Tungsten Carbide Non-standard parts
6. Tungsten Carbide Circular Blade
If have any more doubt, please feel free to contact with me. And welcome to visit our factory.
