High quality ground square tungsten carbide brazed tip for carbide cutting tool
| Place of Origin | China |
| Brand Name | ZhuZhou Top |
| Certification | ISO9001:2015 |
| Grade | ZF00117 |
| Minimum Order Quantity | 100 pcs |
| Price | USD 45-58/kg |
| Delivery Time | 7-15 days |
| Payment Terms | 30% after confirming order the balance before shiping |
| Supply Ability | 100000 pcs/month |
High quality ground square tungsten carbide brazed tip for carbide cutting tool
If have any more information, please feel free to contact with us.
Contact person:Sharon Li
Email:sharon@xtjqxcl.com
Mobile/Whatsapp phone:+86-18973341595
Website:www.qcarbide.com
The tungsten carbide welding cutting blades,brazed tips inserts are used for the turning of cast machining, like cast iron, steel, stainless steel,nonferrous metal and nonmetal, etc.
Features:
1. Top 100% virgin raw material
2. Excellent wear-resistance
3. High impact resistance
4. Stable chemical properties
5. Careful surface treatment and perfect appearance
6. Easier to braze, and long service time
7. Made by precision moulds, better diemsional accuracy and uniform
8. Various types and grades available
Types:
Main Types: A&B5 / A&B6 / A&B8 / A&B10 / A&B12 / A&B16 / A&B50 / etc.
C5 / C6 / C8 / C10 / C12 / C16 / C20 / C25 / C32 / C40 / C50.
D3 / D4 / D5 / D6 / D8 / D10 / D12.
E4 / E5 / E6 / E8 / E10 /E12 / E16 / E20 / E25 / E32 / etc.
F10 / F13 / F 16 / F20 / F25 / F60 / etc.
G8 / G10 / G12 / G16 / G20 / G25 / G30.
K110 / K112 / K114 / K116 / K118 / K120 / K122 / K124 / K126.
K030B/D, K032B/D, K034B/D, K036B/D, K038B/D, K040B/D, K044B, K046B, etc.
Other types,dimensions and customized design are all available.
Grade of some tungsten carbide
| ISO | Grade | Density g/cm3 | Hardness No Less ThanHRA (HV) | TRS No Less Than (Mpa) |
| K10 | YG6A | 14.7 | 91.5 | 1510 |
| K10 | YG6X | 14.8 | 91 | 1560 |
| K15 | YG6 | 14.9 | 89.5 | 1670 |
| K20 | YG8 | 14.6 | 89 | 1840 |
M10 | YW1 | 13 | 91 | 1290 |
| M10 | YW3 | 12.9 | 92 | 1390 |
| M10 | YW4 | 12.3 | 92 | 1390 |
| M20 | YW2 | 12.9 | 90.5 | 1460 |
| P10 | YT05 | 12.6 | 92.5 | 1260 |
| P10 | YT15 | 11.3 | 91 | 1300 |
Type | Dimension(mm) | Approx unit weighting(g) | ||||||
L | t | s | r | YG6 | YG8 | YT5 | YT14 | |
B5 | 5.0 | 3.0 | 2.0 | 2.0 | 0.5 | 0.4 | 0.4 | 0.3 |
B6 | 6.0 | 4.0 | 2.5 | 2.5 | 0.8 | 0.8 | 0.6 | 0.6 |
B10 | 10.0 | 6.0 | 4.0 | 4.0 | 3.2 | 3.1 | 2.7 | 2.4 |
B12 | 12.0 | 8.0 | 5.0 | 5.0 | 6.1 | 6.1 | 5.5 | 4.8 |
B16 | 16.0 | 10.0 | 6.0 | 6.0 | 12.7 | 12.7 | 11.1 | 9.8 |
B20 | 20.0 | 12.0 | 7.0 | 7.0 | 22.4 | 22.4 | 19.6 | 17.2 |
B25 | 25.0 | 14.0 | 8.0 | 8.0 | 38.4 | 38.4 | 32.2 | 28.4 |
